Understanding the Bootstrap 3 Grid System

With the 3rd version of the great  Bootstrap  out for about 4 and a half months now, people have had their time to play around with it, learn the changes, find new features, and build amazing things.

The Difference

The most interesting change for me was the difference in the  grid system. Bootstrap 2 catered to two different browser sizes (desktop and then mobile). With Bootstrap 3, you now build with mobile in mind first, and the grid system lets you create  different grid systems based on browser size.

Bootstrap 2

The grid you create works on desktops and then stacks on top of each other when browser size is below 767px. This is limited since you can only define 1 grid on desktop sized browsers. You are left with a stacked grid on mobile devices.

Bootstrap 3

The new Bootstrap grid system applies to mobile first. When you declare a specific grid size, that is the grid for  that size and above. This can be a little hard to grasp at first so here’s an example.

For example, let’s say you want a site that has:

  • 1 column on extra small devices
  • 2 columns on small AND medium devices
  • 4 columns on large devices

Since the grid system now  cascades up  from mobile devices, this is how this code will look.

We don’t have to define anything for extra small devices since the default is one column. We have to define a grid size for small devices,  but not for medium devices. This is because the grid cascades up. So if you define a size at  sm, then it will be that grid size for  sm,  md, and  lg.

We’ll explain the different grid sizes and how you create them and then show examples.

The Grid Sizes

This is the best part about the new grid system. You could realistically have your site show a different grid on 4 different browser sizes. Below is the breakdown of the different sizes.

.col-xs-$ Extra Small Phones Less than 768px
.col-sm-$ Small Devices Tablets 768px and Up
.col-md-$ Medium Devices Desktops 992px and Up
.col-lg-$ Large Devices Large Desktops 1200px and Up

The  official Bootstrap docs  offer a much more comprehensive understanding of how the grid works. Take a look at those to get a more solid overview of column sizes, gutter sizes, maximum column sizes, and the max-width of your overall site based on browser size.

Default Sizes for the Bootstrap Grid

Sometimes you will need to use media queries to get your site to act the way you’d like it to. Knowing the default grid sizes is essential to extending the Bootstrap grid. We’ve written up a quick tip to show you the default sizes so take a look if you need the Bootstrap media queries and breakpoints.


Responsive Utilities

Just like Bootstrap 2, Bootstrap 3 provides responsive utilities for hiding and showing elements based on the browser size. This will also help us in defining our grid system.

  • .visible-xs
  • .visible-sm
  • .visible-md
  • .visible-lg
  • .hidden-xs
  • .hidden-sm
  • .hidden-md
  • .hidden-lg

This helps because we are able to show certain elements based on size. In our examples today, we’ll be showing an extra sidebar on large desktops.


Here are a few examples of the grids that you can create. We’ll go through some basic sites that some people might want and show how easy it is to build that site with the Bootstrap 3 grid.

Resize your browser’s width to see the different grids in action.

Simple: Large Desktop vs Mobile

Let’s say you wanted a site to have  1 column  on extra small (phone) and small (tablet) devices,  2 columns  on medium (medium desktop) devices, and  4 columns  on large (desktop) devices.

Large Devices!
Large Devices!
Large Devices!
Large Devices!

Here is the code for that example:

Intermediate: Show Extra Column on Large Desktops

This is an interesting example and one that the new grid excels at. Let’s say you have a site that has a sidebar and a main content section. For  extra small devices, you want one column, main content with the sidebar stacked below it. For  small and medium devices, we want sidebar and main content to sit side by side. Now for  large devices, we want to utilize the space on larger devices. We want to add an extra sidebar to show more content.

I am the main content.
I am the main sidebar.
I am the secondary sidebar that only shows up on LARGE devices.

We change the size of the main content to span 6 columns on large devices to make room for our second sidebar. This is a great way to utilize the space on larger desktops. And here is the code for that example.

Advanced: Different Grid For Every Size

This will be a more complex example. Let’s say that at no point in our grid system do we want all of our columns to stack. For  extra small devices, we want 2 columns. For  small devices, we want 3 columns. For  medium devices, we want 4 columns. For  large devices, we want 6 columns (one that only shows on large devices).

You get the drill now. Let’s just straight into the example and code.

I’m content!
I’m content!
I’m content!
I’m content!
I’m content!
I’m content only visible on large devices!

You can see that as the browser size gets smaller, the columns start to form. Also, the content inside each will begin stacking.

It’s Gridtastic!

You can see how easily it is to build complex and dynamic sites with the Bootstrap 3 grid. From mobile 2 column sites to complex hiding and showing elements on large desktops, you can build any type of site. Hopefully these examples will give you an idea of the flexibility of the new grid system and all the great things you can create.
